Light Duty V-Belt Driven Live Roller Curve Conveyor
Standard Specifications
Driving Belt — “B” section V-belt.
Bed — Roller bed width between frames, 10", 13", 16" and 22". 5½" x 1½" x 12 gauge powder painted formed steel channel frame.
Tread Rollers — 1-3/8" diameter x 18 gauge galvanized steel tread rollers, 1½" centers, 5/16" hex shaft for 13"-19" OAW. 2½" to 111⁄16" tapered roller for 25" OAW conveyor, 7/16" hex shaft.
Pressure Sheaves — 3" diameter x 3⁄8" bore, adjustable to give re- quired driving force.
Floor Supports — Adjustable 30" to 44" from floor to top of rollers. One support at each end, center leg on outer rail.
Tangent — 12" long, one on each end.
End Drive — Mounted below bed section.
Bearings — Sealed prelubricated with cast iron housings.
Speed Reducer — C-Face mounted heavy duty worm gear reducer.
Motor — ½ HP 230/460-3-60 TE motor.
Conveying Speed — 60 FPM constant.
Capacity — 300 Ibs. total distributed live load.
Optional Equipment
- ►Guard Rails - Adjustable channel, continuous channel, steel guard rails available.
- ►Floor Supports - Lower or higher supports are available. Minimum elevation 15½".
- ►Ceiling Hangers - ½" diameter threaded rods 8 feet long with locking nuts and mounting hardware. Other lengths are available.
- ►Side Mounted Drive - End drive mounted to side of conveyor bed section. Minimum elevation 8". Specify side.
- ►Minimum tangent length - 18".
- ►Motor - Single phase, energy efficient, explosion proof, etc. Other HP available.
- ►Conveying Speed - Variable and other constant speeds available.
- ►Electrical Controls - Magnetic starters and push button stations; manual motor starters with overload protection, others.
